Walk-behind Scrubber Dryers - Model Range 40 Litres

Gmatic 40 BX 50

Gmatic 40 BX 50















Dimensions

Working width mm 570
Squeegee width mm 780
Dimensions (LxBxH) mm 1.450 x 450 x 950
Operating weight kg 220

Water

Fresh water Liter 50
Water consumption ml/m² 50
Water consumption L/min 1,3
Tank range 1000

Motors

Speed1 km/h 0-6
Differential axle W n/a
Brush motor W 1x 400
Brush speed rpm 150

Batteries

Battery voltage V 24
Battery amps AhC5 85
Performance per hour2
(theoretically)
1.880
Current consumption3 A 28
Battery range (net)3
(by 80% DoD)
h:min 2:20
Battery range3
(by 80% DoD, 4km/h)
 3.900

Lader

Charger A 36
Charging time h 4,5




1 The maximum speed can be parameterized, i.e. limited.
   Working and transport speeds can be set separately.
2 Realistic practical value -40%.
3 in power mode on smooth ground. The value can vary widely.
